Double-door GRP cabinets
CR11 GRP cabinet
A full 2m-wide double-door cabinet with a 500mm body. Built to order in Wales when you need the width, not a deep enclosure.
2m wide, without a deep footprint
The CR11 is 2000mm wide and 500mm deep, with 1600mm clear internal height. It is for wide panels and kit that spread along a wall or fence, where an 800mm cabinet would stand too far into the site.
Same width as the CR12 and the walk-in range. The difference is depth: this is still a cabinet you work from the front, not a housing you walk into.
If you need 800mm of depth at this width, look at the CR12. If you need to get inside and work, look at the walk-in range, starting at the CR13.
The CR11 in numbers
Width and depth are external. Height is clear internal height.
| External width | 2000mm |
|---|---|
| External depth | 500mm |
| Clear internal height | 1600mm |
| Floor / base | Open base with 100mm flange |
| Approx. weight | |
| Doors | Double |
| Lock | Cylinder night latch, or stainless hasp and staple |
| Colour | BS4800 Green (14-C-39) or Grey (10-A-07) |
| IP rating | IP54 |
| Material | Moulded GRP, fire-retardant resin |
What you can add to this size
Jobs this size is made for
Wide roadside cabinets
Long panels that need a 2m opening and a shallow body.
Fence and wall lines
Sites where a deeper cabinet would block a path or compound.
Plinth-mounted installs
Bolt-down housings on a prepared concrete base.
Stepping up from a CR10
More width, less depth.
Deeper, narrower, or walk-in?
CR10
Larger roadside and utility installs needing serious access.
CR12
Full 2m width with 800mm of internal depth.
CR13
Walk-in access with a shallow 500mm footprint.
Ready to quote the CR11?
Tell us how many you need and the delivery postcode. We will come back with a straight price and an honest lead time.
